IPC-B660HA-LZU
ارسال رایگان
گارانتی
مشخصات
کیفیت تصویر6 مگاپیکسل
رزولوشن 3200 × 1800
میکروفوندارای میکروفون داخلی
فاصله کانونیلنز وریفوکال موتوردار 2.8 تا 1...
جنس بدنهفلز و پلاستیک
۷ روز ضمانت بازگشت کالا
ضمانت اصل بودن کالا
هایروکس سیستم
این محصول موجود است.
جهت نمایش قیمت و خرید، سایز محصول خود را انتخاب کنید
جهت نمایش قیمت و خرید، سایز محصول خود را انتخاب کنید
محصولات مشابه
معرفی
- Camera
- Image Sensor
- 1/2.4" Progressive Scan CMOS
- Max. Resolution
- 3200 × 1800
- Min. Illumination
- Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
- Shutter Time
- 1/3 s to 1/100,000 s
- Day & Night
- IR cut filter
- Angle Adjustment
- Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°
- Lens
- Lens Type
- Varifocal lens, motorized lens, 2.8 to 12 mm
- Focal Length & FOV
- 2.8 to 12 mm, horizontal FOV 106° to 35.6°, vertical FOV 55.9° to 20°, diagonal FOV 127.4° to 40.8°
- Lens Mount
- Ø14
- Iris Type
- Fixed
- Aperture
- F1.6
- DORI
- DORI
- D: 68 to 200 m, O: 27 to 79 m, R: 13.6 to 40 m, I: 6.8 to 20 m
- Illuminator
- Supplement Light Type
- IR,White Light
- Supplement Light Range
- Up to 50 m
- IR Wavelength
- 850 nm
- Smart Supplement Light
- Yes
- Video
- Main Stream
- 50 Hz:
- 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
- 60 Hz:
- 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-Stream
- 50 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)
- Video Compression
- Main stream: H.265+/H.265/H.264+/H.264,
- Sub-stream: H.265/H.264/MJPEG
- Video Bit Rate
- 32 Kbps to 16 Mbps
- H.264 Type
- Baseline Profile,Main Profile,High Profile
- H.265 Type
- Main Profile
- Region of Interest (ROI)
- 1 fixed region for main stream
- Bit Rate Control
- CBR,VBR
- Scalable Video Coding (SVC)
- H.264 and H.265 encoding
- Audio
- Audio Type
- Mono sound
- Audio Compression
- G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC
- Audio Bit Rate
- 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)
- Audio Sampling Rate
- 8 kHz/16 kHz
- Environment Noise Filtering
- Yes
- Network
- Protocols
- TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP, UPnP
- Simultaneous Live View
- Up to 6 channels
- API
- Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK
- User/Host
- Up to 32 users
- 3 user levels: administrator, operator, and user
- Client
- iVMS-4200,HiLookVision
- Security
- Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
- Web Browser
- Plug-in required live view: IE 10, IE 11,
- Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
- Image
- Image Settings
- Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
- Day/Night Switch
- Day,Night,Auto,Schedule
- Wide Dynamic Range (WDR)
- 120 dB
- Image Enhancement
- BLC,HLC,3D DNR
- SNR
- ≥ 52 dB
- Privacy Mask
- 4 programmable polygon privacy masks
- Interface
- Ethernet Interface
- 1 RJ45 10 M/100 M self-adaptive Ethernet port
- On-Board Storage
- Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
- Reset Key
- Yes
- Built-in Microphone
- Yes
- Event
- Basic Event
- Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
- Linkage
- Upload to FTP/memory card,notify surveillance center,send email,trigger recording,trigger capture
- General
- Power
- 12 VDC ± 25%, 0.9 A, max. 11 W,Ø5.5 mm coaxial power plug,reverse polarity protection,PoE: IEEE 802.3af, Class 3, max. 12.9 W
- Material
- Metal & Plastic
- Dimension
- Ø105 mm × 252 mm (Ø4.13 × 9.92\")"
- Package Dimension
- 315 mm × 137 mm × 141 mm (12.4" × 5.4" × 5.6")
- Weight
- Approx. 725 g (1.6 lb.)
- With Package Weight
- Approx. 1060 g (2.3 lb.)
- Storage Conditions
- -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Startup and Operating Conditions
- -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Language
- English, Ukrainian
- General Function
- Heartbeat,anti-banding,mirror,password protection,password reset via email
- Approval
- EMC
- CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,
- RCM: AS/NZS CISPR 32: 2015,
- IC: ICES-003: Issue 7
- Safety
- CB: IEC 62368-1: 2014+A11,
- CE-LVD: EN 62368-1: 2014/A11: 2017
- Environment
- CE-RoHS: 2011/65/EU,
- WEEE: 2012/19/EU,
- Reach: Regulation (EC) No 1907/2006
- Protection
- IP67: IEC 60529-2013
مشخصات
IPC-B660HA-LZU
کیفیت تصویر6 مگاپیکسل
رزولوشن 3200 × 1800
میکروفوندارای میکروفون داخلی
فاصله کانونیلنز وریفوکال موتوردار 2.8 تا 12 میلی متر برای نصب و نظارت آسان
جنس بدنهفلز و پلاستیک
مقاومتمقاوم در برابر آب و گرد و غبار IP66
قابلیت تشخیصپشتیبانی از تشخیص انسان و وسیله نقلیه
چراغ هیبریدی هوشمندفناوری پیشرفته با برد طولانی
تصویربرداری ضد نورتصویربرداری واضح حتی با نور پشتی قوی به دلیل فناوری WDR 120 دسی بل
حافظه داخلیتا 512 گیگابایت اسلات کارت SD برای ذخیره سازی
